SALE PRICE £179.97 Bosch GAM 220 MF Angle LEVEL 0601076600 3165140798860 MT
User benefit
- Rapid calculation and transfer of angles by means of memory function for frequently used angle dimensions
- Automatic calculation of single and double mitre angles without any other tools
Other features
- Optimum readability due to rotating, illuminated display
- Hold function for holding and transferring the measuring result at the press of a button
- Precise angle transfer due to mechanical locking screw
- Robust and compact design with IP54 protection
- No calibration required
Technical data
| Measurement range | 0 – 220° |
| Measurement accuracy, angles | ± 0.1° |
| Measurement accuracy, vials | ± 0.05° |
| Accuracy of angle calculation | ± 0.1° |
| Power supply | 4x 1.5 V R6 (AAA) |
| Battery power, approx. | 80 h |
| Automatic deactivation, approx. | 30 mins |
| Arm length | 40 cm |
| Weight, approx. | 1,1 kg |
| Length | 446 mm |
| Width | 52 mm |
| Height | 60 mm |
Functions
| Calculation function |  |
| Memory function | |
